| Код | 165271 |
| Код | 162013 |
Внешний диаметр: 87,6мм
Высота: 226мм
Объем: 0,946л.
Вход/Выход: AN10 (ORB10)
| Код | 74688 |
| Код | 56394 |
| Код | 17142 |
| Код | 215444 |
Внимание!
Комплект кронштейна требует замены приводного ремня на ремень 970мм 5PK970.
| Код | 183095 |
| Код | 176651 |
| Код | 68263 |
| Код | 55939 |
| Код | 45569 |
44mm MVR44 V-Band External Turbo Wastegate Sets
Wastegate comes complete with everything as shown;
V-Band 44mm Wastegate
- Valve seat (Inlet sealing ring) - Stainless Steel 304
- V-band Inlet & Outlet Flanges- Stainless Steel 304
- V-band Inlet & Outlet Clamps - Stainless Steel 304
- Air fittings
- Plugs included for unused ports
- Stainless steel 304 hardware.
FUNCTION:Water Cooler
Factory installed spring is 14 psi , and come 2 springs 7&17psi for spare parts
Come with :
1 x 44mm wastegate
1 set accessory (same as photo show )
| Код | 247572 |
| Код | 144703 |
| Код | 170913 |
| Код | 141996 |
| Код | 55321 |
Product Details:
The BorgWarner EFR 7670 Turbo (179392) is engineered for early spool and capable of 64lb/min compressor flow with unmatched response, EFR 7670 is ideal for road racing and time attack applications, as well as responsive street driven vehicles. BW utilizes their 70mm Gamma-Ti turbine wheel as the optimal match for the 57.2mm inducer / 76mm exducer FMW compressor, and is capable of 45+psi boost. This turbo uses the mid-size EFR ported-shroud compressor housing, great for fitment in cramped engine bays. Ideal for use in single turbo applications for the 400-650hp range (up to 2.8L), or as twin turbo applications 800-1200+hp. Ceramic Ball Bearing only, watercooling recommended.
Compressor Specifications:
-Compressor Type: Forged-Milled Wheel (FMW) Extended Tip
-Compressor Wheel OD (exducer): 76mm
-Compressor Wheel Inducer: 57.2mm
-Max Flow Rate: 64 lb/min
-Built-in BOV: All EFR compressor housings incorporate an integrated BOV.
Compressor Housing Connections:
-Inlet: 3.5" Hose Coupler
-Outlet: 2.0" Hose Coupler
Turbine Specifications:
-Turbine Type: Low Inertia Gamma-Ti Turbine Wheel
-Turbine Wheel OD: 70mm
-Stainless Steel Sand cast Housing
-1.05 A/R T4 Twin Scroll (External WG)
Product Features:
-Dual Row Ceramic Ball Bearings - lowest friction and fastest spool/response, most extreme durability, built-in oil control orifice - (aka oil restrictor)
-Watercooled Center Section - watercooling is recommended, 14mm banjo bolts
-Double seals on both turbine and compressor end for extreme durability and resistance to any oil seepage
-Boost Control Solenoid Valve Integrated to Compressor Housing
-Integrated Speed Sensor mounting provisions
| Код | 46479 |
