| Код | 56393 |
Product Details:
The BorgWarner EFR 7064 (179389) Turbo is an excellent turbocharger for drift, road racing and street driven applications. The 7064 delivers incredibly fast spool and response while working well on stock and heavily modified engines. The 70mm OD compressor has a 52.2mm inducer and at 56lb/min max flow - there is potential for 560hp - unheard of for this size compressor wheel. The low inertia 64mm Gamma-Ti turbine wheel is the optimal match for the 70mm FMW compressor wheel and is capable of 45+psi boost. This turbo uses the mid-size EFR ported-shroud compressor housing, great for fitment in cramped engine bays. Ideal for use in single turbo applications for the 350-560hp range, or as twin turbo applications 650-1000+hp. Ceramic Ball Bearing only, watercooling recommended.
Compressor Specifications:
-Compressor Type: Forged-Milled Wheel (FMW) Extended Tip
-Compressor Wheel OD (exducer): 70mm
-Compressor Wheel Inducer: 52.2mm
-Max Flow Rate: 56 lb/min
-Compressor Housing: 3.5" Ported shroud inlet, 2.0" hose coupler outlet
-Built-in BOV: All EFR compressor housings incorporate an integrated BOV.
Connections:
-Inlet: 3.5" Hose Coupler
-Outlet: 2.0" Hose Coupler
Turbine Specifications:
-Turbine type: Low Inertia Gamma-Ti Turbine Wheel
-Turbine Wheel OD: 64mm
-Stainless Steel Sand cast Housing
-0.92 A/R T4 Undivided (Internal WG)
-Turbine outlet: GT-Vband (aka small 3" vband) ~92mm OD for all EFR turbos
Product Features:
-Dual Row Ceramic Ball Bearings - lowest friction and fastest spool/response, most extreme durability, built-in oil control orifice - (aka oil restrictor)
-Watercooled Center Section - watercooling is recommended, 14mm banjo bolts
-Double seals on both turbine and compressor end for extreme durability and resistance to any oil seepage
-Boost Control Solenoid Valve Integrated to Compressor Housing
-Integrated Speed Sensor mounting provisions
| Код | 46480 |
| Код | 167810 |
| Код | 55963 |
GENESIS COUPE 2.0T Theta G4KC 2008~
Flange: STD Genesis
Actuator: 0.8BAR
Replacement for: Stock TD04L Turbo P/N 49377-06902, etc
Max HP: 320+
TURBINE:
Wheel: TD05H
Diameter: 49.2/55.8 mm
A/R: 57
Nozzle area: 8cm²
COMPRESSOR:
Wheel: 20G
Diameter: 52.5/68 mm
CFM: 640
| Код | 45301 |
| Код | 72734 |
| Код | 47407 |
| Код | 156712 |
| Код | 01738 |
Бренд SIRUDA основан в 2010 году, и на сегодняшний день является немало известным производителем автомобильных прокладок как для бензиновых, так и для дизельных двигателей. Имея богатый профессиональный опыта производства, SIRUDA не уступает конкурентам по качеству своей продукции. Высокая точность изготовления прокладок с максимальным допуском +/- 0,001 достигается самыми современными технологиями и оборудованием.
Целью компании SIRUDA является обеспечение высокого качества продукции для удовлетворения потребности покупателя. Особое внимание уделяется двигателям с турбонаддувом, работающим в экстремальных условиях.
| Код | 38298 |
| Код | 56337 |
Turbo Speed Gauge (TSG-1)
The Turbo Speed Gauge (TSG-1) monitors turbo speed, and a whole lot more
- Plug and play solution for turbos outfitted with BorgWarner turbo speed sensors
- Includes open auxiliary channels for other devices such as MAP, Thermocouples, and Pressure Transducers
- Able to pass speed sensor and auxiliary channels through to data acquisition and/or engine ECU
- Graphically plots speed on a scrolling screen
- Converts speed to 0-5v signal
- Easily configurable for all BorgWarner turbocharger rotor groups
TSG-1 SPECIFICATIONS:
• Compact 2 1/16” circular gauge
• 128 x 64 pixel graphical display
• Pairs with turbo speed sensor
• 12-bit 0-5 volt analog input
for MAP / pressure sensors
• 12-bit 0-5 volt analog output
for ECU and/or datalogging
| Код | 158596 |
| Код | 79928 |
| Код | 85890 |
| Код | 82035 |
| Код | 75735 |
| Код | 28267 |
| Код | 44438 |
| Код | 167814 |
