Артикул:
R
Код
—
75752
Каталожный номер
—
120-13430-BK
Product Specifications
Rotor Compatibility
Rotor Width (in) 0.38
Maximum Rotor Width (in) 0.38
Minimum Rotor Width (in) 0.25
Maximum Rotor Diameter(in) 13.00
Minimum Rotor Diameter(in) 10.00
Brake Pad Specifications
Brake Pad Type 1 6712
Brake Pad Type 2 N-A
Brake Pad Type 3 N-A
Total Pad Area (in²) 7.3
Total Pad Volume (in³) 2.4
Piston Specifications
Piston 1 Bore (in) 1.62
Piston 2 Bore (in) 1.38
Piston 3 Bore (in) 1.38
Total Piston Area (in²) 5.06
Mounting Specifications
Mount Type Lug
Mount Side Right Hand
Mount Center(in) 5.25
Mount Hole Size(in) 0.39
Mount Height(in) 2.03
Inlet Thread Size 1/8-27 NPT
Parts & Accessories
O-Ring Kit 130-10535
Replacement Dust Boot N-A
Replacement Piston 1 200-7520
Replacement Piston 2 200-7518
Replacement Piston 3 200-7518
Replacement Piston 4 N-A
Cross-Over O-Ring Kit 130-10540
Bridge Bolt Kit N-A
Wear Plate L/H 300-9707
Wear Plate R/H 300-9707
Pad Retainer N-A
Bleed Screw Kit 220-0627
Self Bleeder Tube N-A
Cross-Over Tube N-A
