- BEARING SYSTEM Journal Bearing
- COOLING SYSTEM Oil and Water Cooled
- COMPRESSOR
WHEEL DIAMETER
Inducer (mm) 50.3
Exducer (mm) 68
Blades 6/6
- COVER DIAMETER
Inlet (mm) 51.2
Outlet (mm) 40.8
Boost Pressure @ 1 bar (14.7 psi)
CFM 600
lb/min 41.4
A/R 0.55
- TURBINE
WHEEL DIAMETER
Inducer (mm) 61
Exducer (mm) 54.1
Blades 11
FLANGE STD SUBARU / IMPREZA
NOZZLE AREA (cm^2) Mitsubishi SPEC 7
A/R Garrett SPEC 0.49
ACTUATOR Standard @ 14.7 psi
ENGINE SIZE 2.0~2.5L
HORSEPOWER (BHP) 350 - 400
Install Kit includes
- 1 x braided steel oil feed line kit with two banjo bolt kit to turbo and engine.
- 1 x oil drain pipe kit (38mm flange / M6 bolt)
- 1 x water feed pipe kit with 14mm bolt.
- 1 x water drain pipe kit with 14mm bolt
- 1 x turbine inlet gasket
- 1 x turbine outlet gasket
